How does a mobile pump truck work?

Oct 20, 2023

A mobile pump truck, often referred to as a concrete pump truck or simply a pump truck, is a specialized vehicle used in construction to transport and pour concrete. It works by using a combination of hydraulic systems and a large articulated boom equipped with a concrete pump. Here's how a mobile pump truck typically works:

  1. Concrete Mixing: Before the concrete is pumped, it must be mixed at a concrete batch plant. This is usually done using a stationary concrete mixer. The mixed concrete is then loaded into the hopper of the pump truck.

  2. Positioning: The mobile pump truck is driven to the construction site and positioned in a location where it can access the desired pouring area. The truck needs to be placed on stable ground to support its weight and the force of the concrete being pumped.

  3. Setup: Once the truck is in position, the outriggers are extended to stabilize the vehicle. Outriggers are hydraulic legs that extend from the sides and rear of the truck to provide stability during the pumping process.

  4. Boom Operation: The key component of the pump truck is its articulated boom. This boom is usually a multi-section, hydraulic arm that can extend, bend, and rotate. The operator controls the boom using a remote control panel. By adjusting the boom's position and angle, the operator can direct the flow of concrete precisely where it's needed.

  5. Pumping: The concrete is pumped from the hopper through a large, flexible hose or pipe that's attached to the end of the boom. The concrete pump itself uses a hydraulic system to draw concrete from the hopper and then pressurize it. The pressurized concrete is then forced through the hose or pipe and directed by the boom to the desired location. The concrete is pumped at a controlled rate to ensure even and accurate placement.

  6. Continuous Flow: The pump truck allows for a continuous flow of concrete, which is especially useful for large or complex construction projects. This method is faster and more precise than traditional methods of concrete pouring, such as using a chute from a stationary mixer.

  7. Cleanup: After the concrete pouring is complete, the pump and hoses must be cleaned to prevent the concrete from setting inside the equipment. Water is often used to flush the system, and the remaining concrete slurry is collected and disposed of properly.

Mobile pump trucks are particularly useful for high-rise buildings, large concrete pours, and projects with challenging access or unique architectural requirements. They provide a more efficient and accurate means of placing concrete compared to manual methods and stationary concrete mixers.
