Does every building have a fire pump?

Jul 08, 2025
Share:

In modern fire protection systems, fire pumps are essential components for delivering sufficient water pressure to fire sprinklers and standpipes. But one common question asked by building owners, designers, and even facility managers is: Does every building require a fire pump?

The answer is not as simple as a “yes” or “no.” Fire pump requirements vary depending on several factors, including the building's size, height, function, occupancy, and the available water supply pressure. In this article, we’ll clarify when a fire pump is necessary, which types of buildings typically require them, what standards like NFPA 20 say, and why it matters for safety and code compliance.


What Is a Fire Pump?

A fire pump is a critical component of a fire protection system that boosts water pressure to ensure adequate flow to sprinklers and standpipes, especially in buildings where the water supply pressure is not sufficient. Fire pumps are commonly powered by electric motors or diesel engines and are activated either automatically by a drop in pressure or manually.

According to NFPA 20, the standard for the installation of stationary fire pumps, a fire pump is required when the water supply available (either from the municipal main or a water tank) does not meet the pressure and flow demands of the fire protection system.


When Is a Fire Pump Required in a Building?

Fire pumps are not mandated in every building. Their necessity depends on:

1. Building Height

Tall buildings often require fire pumps because municipal water pressure is typically insufficient to reach upper floors. For example, high-rise buildings—often defined as those exceeding 75 feet (23 meters)—usually need a fire pump to deliver the required pressure to upper-level sprinklers and hose connections.

2. Water Supply Pressure

If the incoming water pressure is too low to satisfy the hydraulic demand of the sprinkler system, a fire pump is needed to boost that pressure. This is common in areas with unreliable municipal supply or where pressure fluctuates during peak usage times.

3. System Demand

If the fire protection system (sprinklers, standpipes, hose reels) requires more water pressure or volume than the supply provides, a fire pump becomes necessary. For instance, warehouses with extensive in-rack sprinkler systems often have high demand and require fire pumps.

4. Occupancy Type

Some occupancy types, such as industrial facilities, hospitals, or data centers, require higher levels of fire protection due to the presence of hazardous materials or sensitive operations, increasing the likelihood of fire pump requirements.

5. Code and Local Jurisdiction

Local fire codes and building codes may dictate when a fire pump is required. Most jurisdictions follow NFPA standards, but local amendments may apply. Always consult the Authority Having Jurisdiction (AHJ) or a fire protection engineer when designing a system.


Common Building Types That Typically Require Fire Pumps

Although not universal, the following buildings commonly require fire pumps:

  • High-rise residential and commercial towers

  • Hospitals and healthcare centers

  • Large shopping malls

  • Airports and transportation hubs

  • Industrial and manufacturing facilities

  • Warehouses and logistics centers

  • Hotels and resorts with multiple floors

  • Data centers and server farms

These structures often exceed the pressure capabilities of standard municipal supplies, and therefore rely on fire pumps to maintain system performance.


Buildings That May Not Need Fire Pumps

Smaller buildings, such as:

  • One- or two-story retail stores

  • Low-rise office buildings

  • Detached residential homes

  • Small warehouses or storage units with gravity-fed tanks

…may not require a fire pump, especially if their water pressure meets system demands without boosting.

However, this determination must still be made through hydraulic calculations during the design phase.


NFPA 20 and Fire Pump Requirements

The NFPA 20 Standard for the Installation of Stationary Fire Pumps provides clear guidance on when and how fire pumps should be installed.

Some key points include:

  • Fire pumps must be listed for fire service.

  • The pump room must be properly enclosed, ventilated, and protected.

  • A reliable power source must be provided (diesel backup or dual electric feeds).

  • Acceptance testing and performance curves are required to validate pump performance.

  • Fire pumps must not be shared with domestic water systems unless permitted by code.

Importantly, NFPA 20 does not explicitly state which buildings require a fire pump—it explains how to design and install one when needed. The necessity is generally governed by NFPA 13 (for sprinklers), NFPA 14 (for standpipes), and the International Building Code (IBC).


How to Determine If Your Building Needs a Fire Pump

If you're constructing or retrofitting a building and unsure whether a fire pump is required, follow these steps:

1. Conduct a Hydraulic Demand Calculation

This determines the water flow and pressure required by the sprinkler and standpipe systems. Compare this to the water supply's capabilities.

2. Assess the Water Supply

Evaluate the municipal or onsite water source pressure under both static and residual conditions. If it's insufficient, a fire pump will likely be needed.

3. Consult the Codes

Review applicable codes like NFPA 13, 14, and 20, along with local building codes and insurance guidelines (such as FM Global or UL requirements).

4. Engage a Fire Protection Engineer

A certified engineer can model the system, verify compliance, and help select the right fire pump model and configuration (horizontal split case, vertical turbine, end suction, etc.).


Why Some Buildings Avoid Fire Pumps

Some developers aim to avoid installing fire pumps due to:

  • Cost: Pumps, controllers, and enclosures add capital and maintenance costs.

  • Complexity: Requires regular testing, power backup, and maintenance.

  • Space: Fire pump rooms must be properly sized and located.

  • Code alternatives: In some areas, gravity-fed tanks or pressure-regulating valves may be used instead.

However, these trade-offs must be weighed against life safety, insurance requirements, and legal liability.


The Bottom Line: Does Every Building Have a Fire Pump?

No, not every building has a fire pump—and not every building needs one. But for many modern structures, particularly high-rise and large-scale facilities, a fire pump is not just recommended—it is essential.

Proper fire pump selection, installation, and testing are vital to keeping occupants safe, protecting property, and complying with code.

If you're unsure whether your building needs a fire pump, consult an experienced fire protection professional or reach out to a trusted manufacturer. At Better Technology Group, we specialize in UL-listed and NFPA 20-compliant fire pump systems tailored to your building’s specific needs.


Final Thoughts

Fire pumps aren’t one-size-fits-all. Their necessity depends on various technical and regulatory factors. The decision to install one should always be based on precise engineering analysis and compliance with recognized standards.

If you're planning a fire protection system and want peace of mind, speak with our experts today. We’ll help you design a reliable, efficient, and code-compliant fire pump solution that keeps your property protected.
